Eahora Romeo

2023 Release

Meet Romeo, designed for riders who want adventurous and long last cycling. The best 48V ebike battery made by EV-class safety standards with 60Ah capacity. Ride for longer distances now, no more worrying about running out of power. Featuring a moped style design frame crafted from high-quality carbon steel, beyond exceptional traction and handling.

• 27 - 29 MPH
  for PAS & throttle

• 106 - 116 MILES
  range per charge

• 60AH 2.88KWH
  48V battery

1/3 Romeo's Unstoppable Drive System

1,000W DC Geared Hub Motor

Enjoy the thrills of a new generation high-rpm brushless motor with 1,000W rated, 1,200W peak output, and 110N.m max torque. The new upgraded controller with 25A output makes it easier than ever to ride up hills and tackle challenging terrain.

Torque: 90N.m
Gradeability: 30° - 40°

2/3 Romeo's Unstoppable Drive System

48V 2.88kWh Lithium-Ion Battery

The 60Ah largest battery capacity of the 48v e-bike has EV-class safety standards to ensure safe storage and maximally extend your riding range. Revel in its superior energy density, minimal self-discharge, and unmatched security compared to traditional lithium-ion counterparts.

Range Throttle: 74 - 80 Miles
Range Pedal-Assist: 106 - 116 Miles

3/3 Romeo's Unstoppable Drive System

3.5" Full-Function Control Color LCD

Track your ride and bike status with the user-friendly YL81F display. The colored screen can show the speed, battery, and mileage. It also allows you to ride in 5 levels pedal assist, full-speed throttle, 6km/h walk, and cruise control modes.

Login Password: Supported (DEFAULT: 1212)
Cruise Control / Walk Mode: Supported

Size and Geometry

Recommended Rider Height: 5'7" - 6'4" or 170CM - 195CM

Ⓐ - Total Length: 79.1" or 201CM

Ⓑ - Wheel Base: 50.4" or 128CM

Ⓒ - Seat Height: 34.3" or 87CM

Ⓓ - Handlebar Height: 44.5" or 113CM

Ⓔ - Rim Diameter: 24" or 57.5CM

Ⓕ - Standover: 26.4" or 67CM

Ⓖ - Reach Distance: 21.3" or 54CM

Ⓗ - Chain Stay Length: 22.0" or 56CM

Ⓘ - Seat Angle: No Actual Seatpost

Ⓙ - Seat Tube Length: No Actual Seat Tube

Ⓚ - Bike Width: 28.7" or 73CM

Ⓛ - Top Tube Length: 28.0" or 71CM

Technical Specifications:

Bike Class:
Class 3 ebike with 5-level pedal assist and throttle.

Bike Weight:
124.6 lbs in total with the battery. The battery weighs 27.6 lbs.

Range per Charge:
74 - 80 miles on throttle mode. 106 - 116 miles on pas mode.

Payload Capacity:
Recommend rider weight within 330lbs.

Electronic System:

Motor:
1000W DC hub motor, cassette; rated torque: 90N.M.

Battery:
48V 60AH (2.88KWH) lithium battery.

Controller:
48V, 25 ± 1A; 12MOS.

Charger:
54.6V ~ 6A smart charger; input 100-240V 50/60HZ. Charging hour: 8-10 Hours.

Display:
4" portrait color display(YL-81F), brightness: 100CD/M2.

Lights:
Front light with 48V 20W LED light, rear light with brake signal and turn signal blinker.

Wiring:
Wiring harness with water-resistant connectors.

Waterproof Rates:
IP65 Waterproof, including motor battery, display and wiring.

Bicycle Components:

Frame:
Carbon Steel; frame size: 26" * 18"

Brakes:
180MM front and rear hydraulic disc brakes, dual piston brake caliper.

Brake Levers:
Aluminum alloy levers with motor cutoff switch.

Tires:
26" * 4" CST tires; tire pressure marked on sidewall.

Fork:
100MM travel mechanic suspension alloy fork.

Rear Suspension:
50MM adjustable air valve shock absorber.

Chain:
T50 alloy steel rust-resistant chain; 126 segments.

Crank Set:
44T * 170MM, dual-sided chainring guard.

Shifters:
Shimano 7 Speed(ASLTX50R7CT), 22.2MM * 2400MM.

Derailleur:
Shimano 7 Speed(RD-TY300).

Freewheel:
Shimano 7 Speed(MF-TZ500-7),14-28T.

Grip:
Comfort rubber ergo grips.

Handlebar:
Rise Handlebar, w 720 * φ 22.2.

Pedals:
9/16, polymer bearing.

Headset:
Integrated threadless headset.

WHAT'S IN THE PACKAGE

Delivered with 85% assembled:
Ebike & battery;
Original charger & adaptor;
Front tire & Headlight;
Pedals & rear lights;
Product manual;
Screws and tools for assembly.

FAQ

What is the top speed of the pedal assist and throttle?

• According to our real-world test, the Romeo can reach up to 27 mph - 29 mph (the Romeo Pro is 29 mph - 32 mph) for both pedal assist and throttle. The test rider weighs 165lbs and rides on a paved surface.

How can the seat of the Romeo bike be raised up? Would need it to be higher.

• The seat height of our Romeo is not adjustable. The only solution is to replace it with a thicker seat.
