EAHORA Juliet
2023 New Release

Meet Juliet, designed for riders who want reliable and long last cycling. The best ebike battery made by EV-class safety standards with 48V 60Ah capacity. Ride for longer distances now, no more worrying about running out of power. Featuring a step-thru design frame crafted from high-quality steel, providing exceptional strength and durability.

Features

1000W Brushless Motor

Enjoy the thrills of new generation motor with 1000W rated, 1200W peak output, and 110 max torque. The new upgraded controller with 25A max output makes it easier than ever to ride up hills and tackle challenging terrain.

Torque: 90N.m
Gradeability: 30°-40°

48V 60AH Battery

The largest battery capacity ebike battery with EV-class safety to maximally extend your riding range. Revel in its superior energy density, minimal self-discharge, and unmatched security compared to traditional lithium-ion counterparts.

Throttle Mode Range: 78-84 Miles
PAS Mode Range: 110-120 Miles

Color LCD Display

Five-level pedal assist and equip twist throttle can achieve the same speed in electric mode. Featuring pushing mode and cruising mode make more functionality and usability during cycling.

Size and Geometry

Recommended Rider Height: 5'4" - 6'4" or 165CM - 195CM

Ⓐ - Total Length: 72.05" or 183CM

Ⓑ - Wheel Base: 48.8" or 124CM

Ⓒ - Seat Height: 32.3" - 40.2" or 82CM - 102CM

Ⓓ - Handlebar Height: 42.5" or 108CM

Ⓔ - Rim Diameter: 16.4" or 42CM

Ⓕ - Standover: 24.2" or 61.5CM

Ⓖ - Reach Distance: 22.8" or 58CM

Ⓗ - Chain Stay Length: 18.9" or 48CM

Ⓘ - Seat Angle: 74.7°

Ⓙ - Seat Tube Length: 10.6" or 27CM

Ⓚ - Bike Width: 28" or 71CM

Ⓛ - Top Tube Length: 23.6" or 60CM

Technical Specifications

Bike Class:
Class 3 ebike with throttle and pedal asssit functions.

Bike Weight:
116lbs in total with the battery.

Range per Charge:
78 - 84 miles on throttle mode. 110 - 120 miles on pas mode.

Payload Capacity:
Recommend rider weight within 330lbs.

Electronic System:

Motor:
1000W DC hub motor, cassette; rated torque: 90N.M.

Battery:
48V 60AH (2.88KWH) lithium battery.

Controller:
48V, 25 ± 0.5A; 12MOS.

Charger:
54.6V ~ 8A smart charger; input 100-240V 50/60HZ. Charging hour: 6-8 Hours.

Display:
4" portrait color display(YL-81F), IP65 Waterproof; brightness: 100CD/M2

Lights:
Front light 48V 8W LED light; rear integrated brake lights, turn-signal lights.

Wiring:
Water resistant connectors and wiring harness.

Waterproof Rates:
IP65 Waterproof, including motor battery, display and wiring.

Bicycle Components:

Frame:
Carbon Steel; frame size: 20" * 18".

Brakes:
180MM front and rear hydraulic disc brakes.

Brake Levers:
Aluminum alloy comfort grip levers with motor cutoff switch.

Tires:
20" * 4" CST tires; tire pressure marked on sidewall.

Fork:
80MM travel mechanic suspension alloy fork, adjustable.

Rear Suspension:
35MM Travel Spring suspension(HLT-100) * 2.

Chain:
DG50 chain.

Crank Set:
48T * 165MM, dual-sided chainring guard.

Shifters:
Shimano 7-speed.

Derailleur:
Shimano 7-speed.

Freewheel:
Shimano 7-speed, 14-28T.

Grip:
Comfort rubber ergo grips.

Handlebar:
BMX handlebar.

Pedals:
9/16, polymer bearing.

Headset:
Integrated threadless headset.

Rack:
Customized steel rear rack.

Kickstand:
Aluminum alloy kickstand with plastic foot.

Fenders:
Custom fat tire fenders, no bracket arm.

Saddle:
Comfort leather saddle.

Rims:
Aluminum 36H spoke wheel.

Seatpost:
Aluminum seatpost with clamp.

Bell:
Electric horn integrated into the headlight.

WHAT'S IN THE PACKAGE:

Delivered with 85% assembled:
Ebike & battery;
Original charger & adaptor;
Front tire & quick release;
Headlight;
Pedals, saddle;
Fenders;
Product manual;
Screws and tools for assembly.

FAQ

What is the IP rating of the Juliet bike? Can I ride it in the rain?

- Our Juliet is IP54 for outdoor use. You can ride it in the rain but should park it under the roof if rains.

Can the brightness on the display be adjusted? I can hardly see the speed when riding.

- The brightness of the display is not adjustable. We'd recommend you try to adjust its position (by rotating the display bracket more vertically) to tune the readability under sunlight.

Is it hard to handle with the 125 lbs weighted bike?

- It's no more difficult to handle on riding than other 45-70lb bikes while it's harder to walk home or lift for storage/ transport.

Should I charge the battery after every ride? I don't want to get this expensive battery broken after the warranty expires.

- You can, but do not have to. The lithium battery allows charging it after every ride to stay in full or charge after runs out. Both of these charging preferences will not shorten the lifespan (or reduce the charging cycles) of it. But for long-term storage (winter or other situations,) 40-60 percent charged and check & recharge monthly is the best.

Is this Juliet model considered as a female bike? I'm considering between the Juliet or Romeo.

- Many customers may think Juliet is a female bike with first sight to the step-through frame and BMX handlebar bike. But in our original design, Juliet is a good workhorse for customers who spend a lot of time through the streets. Obviously, the step-thru frame is the most practical design for frequently getting off and back on it, the wider BMX handlebar is easier to handle and more comfortable for long-lasting rides.

When can I order a battery for my Juliet/Romeo?

- Batteries for Juliet and Romeo are currently in production and are expected to be available in July. We will keep website updated with product information and notify you via email once they are in stock.

Note: Availability is subject to change without prior notice. Please verify availability of item before placing an order by clicking the chat button or contacting us at (833) 867-7437 between 9:00 AM - 5:00PM Central.
